EQUIPMENT & TESTING
Production Equipment & Inspection
Production Equipment & Inspection at GUANWEIER, a one-stop PCBA and EMS manufacturing partner in Fuhai, Bao'an, Shenzhen.
VERIFIED EVIDENCE
Manufacturing capability and control evidence
Public manufacturing facts and control checkpoints help engineering and sourcing teams assess project fit.02
7,000 m²Manufacturing space
03
200+Professional team
04
30M pts/dayPlacement capacity
CAPABILITY OVERVIEW
Production Equipment & Inspection
Production Equipment & Inspection at GUANWEIER, a one-stop PCBA and EMS manufacturing partner in Fuhai, Bao'an, Shenzhen.
01
Controlled scope
Applicable manufacturing, sourcing, inspection, testing and delivery work is defined against the approved project inputs.
02
Risk-based planning
Engineering, material, process, quality and schedule risks are reviewed before work is released.
03
Verifiable delivery
Programs, process criteria, inspection results and changes remain controlled through NPI and production.
EQUIPMENT MATRIX
Core production and inspection equipment
Core equipment supports solder paste printing, 3D SPI, high-speed placement, reflow, AOI, X-Ray, first-article inspection, electrical measurement and functional verification.
01
High-speed placement machine
High-speed, high-precision component placement
02
Automatic solder paste printer
Controlled solder paste printing and process setup
03
3D SPI
Solder paste volume and offset measurement
04
Reflow oven
Controlled temperature zones and reflow profiles
05
Inline AOI
High-volume visual solder-joint screening
06
X-Ray
Hidden-joint inspection for BGA and QFN packages
07
FAI inspection
First-article component, joint and parameter verification
08
LCR meter
Resistance, capacitance and inductance measurement
09
Functional test
Project-level function verification and result control
FAQ
Questions about Production Equipment & Inspection
Project-specific limits and standards are confirmed during review.
Gerber, BOM, CPL / PnP, quantity, test, programming, packaging and target delivery requirements are recommended.
