What data should we provide?

Gerber, BOM, CPL / PnP, quantity, test, programming, packaging and target delivery requirements are recommended.

Can GUANWEIER sign an NDA?

Yes. Select the NDA requirement in the RFQ form and a project manager will confirm the scope and signing method.

No. PCB limits, package limits, test coverage and project lead time are confirmed against actual project data.

The project team confirms the data scope before engineering, material and manufacturing review.

TECHNICAL NOTE

PCBA Quotation & DFM Data Checklist at GUANWEIER, a one-stop PCBA and EMS manufacturing partner in Fuhai, Bao'an, Shenzhen.

ENGINEERING KNOWLEDGE

Organized around inputs, engineering decisions and deliverables without repeating the site-wide manufacturing flow.

Confirm Gerber, drill, BOM, CPL, PCB specifications, test points and revision consistency.

Input · Design dataOutput · Completeness list

Review panelization, pads, orientation, solderability, inspectability and special-process boundaries.

Input · Process limitsOutput · DFM issue list

Assign ownership, conclusions and revisions before releasing controlled prototype inputs.

Input · Confirmed answersOutput · DFM report
